iPEK AGILIOS XR100

iPEK AGILIOS XR100

iPEK AGILIOS XR100 – Push-rod sewer inspection system (100 m)

The iPEK AGILIOS XR100 is a modular push-camera system with a 100 m reinforced push rod for rapid, high-quality inspections from DN50 up to DN300. It’s built to document defects and hand over reports on site—with integrated damage catalogues and a WinCan interface for office workflows.

Features
Why it stands out
  • Right reach & rugged build: 100 m rod (Ø 11 mm) on a serviceable coiler with meter counter and reel brake; XR100 coiler includes integrated wheels for easy handling.
  • Pan-tilt capability: Works with the PTP50 head for endless rotation, wide pan range, and 90° bend navigation from DN75; laser measurement and integrated sonde for location.
  • Field-ready control: VC500 mobile unit—10.1″ touch display, IP55, 128 GB internal memory, daylight-readable—supports standards-based reporting and easy data export (USB/Wi-Fi/LAN).
  • Reporting made simple: On-site documentation with integrated damage catalogues and WinCan export for downstream processing.
  • Hazardous area option: Available as XR100 EX, ATEX Zone 1 (gas) certified for work in potentially explosive atmospheres.
Typical applications

Property drainage and laterals, municipal mains, industrial lines, and inspections in hazardous zones where a portable, bend-capable HD push system with robust reporting is essential.
