It can also be combined with Senceive’s world-leading triaxial tilt sensor to obtain high precision tilt measurements that are linked to an external reference.
Optical Displacement sensing is perfect for many applications, including those measuring: Convergence/divergence for Tunnel/Arch intrados or bridge abutments Vertical movements for structural settlement/heave Lateral movements such as rail track slew Earthworks and embankment movement Water level monitoring / Dewatering.
Features
- Fully integrated unit Extremely low noise performance
- Optical sensor resolution of 0.1mm and repeatability of ± 0.15mm
- Triaxial tilt sensor resolution of 0.0001° (0.0018mm/m) and repeatability of ±0.0005° (±0.009mm/m)
- Integrated long life battery 10 years battery life, including when acting as a relay node within the mesh communications network
- Easy to align with target when using the magnet triggered aiming mode
- Integrated temperature sensor
- Versatile mounting options
- Waterproof to IP66/IP67/IP68
- Firmware is remotely upgradeable over the air via the gateway reducing costly site visits
